Application of LED display screen
1,Advertising LED display
2,Stadium LED screen
3,Transportation traffice LED VMS display
4,Stage rental LED sign
Features
1) Efficient and energy saving
2) Full color and High definition
3) Long life span,Environment-friendly
4)140 ° viewing angle High-brightness
5) Wide range of application
Specs for P8 VMS mobile advertising display
| Model No: | P8 |
| Pixel Pitch | PH8mm(Outdoor) |
| Module Resolution(W*H) | 32(W)*16(H) |
| Pixel Configuration | 1R1G1B(3 in 1) |
| LED Encapsulation | White SMD 3535 |
| Pixel Density | 27777 Pixel /m2 |
| module size | 256*128mm |
| Driving Method | 1/4 scan |
| Refresh Frequency | >1000HZ |
| Driver IC | MBI5124 |
| Grey Scale | 14Bit(depending on the system and IC configuration) |
| Cabinet Size | 1024*1024mm |
| Brighthess | 6200nits |
| weight | 40KG/PCS |
| Color Temperature | 8000K±500(adjustable) |
| Viewing Angle | Horizontal 140°Vetical 120° |
| Optimal Viewing Distance | >8m |
| Working Voltage | AC 220V/110V±10% |
| Module voltage | DV 5V |
| Max Power Consumption | 500W/sqm |
| Avg.Power Consumption | 250W/sqm |
| Life time | 50000 hours |
| Operating Temperature | -10ºC ~ 65ºC |
Other models of pixels pitch led display board
| Pitch (mm) | Density (dot/sqm) | Module (H*W/dot) | Size for modules H*W(mm) | Led chips brand and model | Scan mode | standard cabinet size | Power supply |
| P4 | 62500 | 32*64 | 128x256 | Nationstar,1921LEDs | 1/8 | 1024x1024mm | Meanwell 5V60A |
| P5 | 40000 | 32*32 | 160*160 | Nationstar,2727LEDs | 1/8 | 960x960mm | |
| P6 | 27777 | 32*32 | 192*192 | Nationstar,3535LEDs | 1/8 | 960x960mm | |
| P8 | 15625 | 16*32 | 128*256 | Nationstar,3535LEDs | 1/4 | 1024x1024mm | |
| P10 | 10000 | 16*32 | 160*320 | Nationstar,3535LEDs | 1/2 | 960x960mm |
P8 led module
1. SMD3535
2. Module size: 320*160mm
3. Module Resolution: 40*20dots
4. scan mode: 1/5 or 1/4 scan
Power supply
1. G-energy/Rong-Electronic/MW power supplies
2. Novastar/Linsn/Colorlight/Showbox control system
Cabinet
1. Waterproof iron cabinet
2. size: 640mmx640mm/1024*1024mm(customization)
Workshop
Famous cooperation brand
CE/RoHS certificate
FAQ:
1) Q: How can I place an order and how it works?
A: Generally, first, we could make samples for customers, according to the artworks, affirmed material, processing or workmanship. After the sample is confirmation, we will produce the mass production. And, meanwhile, we will show you the pre production.
2) Q: What's the shipment method?
A: We often use DHL, FEDEX. UPS, TNT or Sea Shipping to ship our products.
3) Q: What's the payment method?
A: You can pay by L/C, T/T, Western Union
4) Q: Can I have samples to test the quality?
A: Yes, you can buy any sample to test the quality.
5) Q: What's the delivery time and can you lower the price?
A: It depends on your order and which shipping way you choose.The delivery time is usually within 7-9 business days. If you have placed an order of large quantities, then, of course, the price can be lowered.
6) Q: Do you accept OEM/ODM for LED Display Screen Sign?
A: Yes, OEM/OEM is welcome.
