E-F4 SERIES Product Features:
The first design in China which the screen is 360° rotated
Fashion appearance , science and technology move feeling
Imported hydraulic system, security and stability
Optional solar battery power supply
|Aggregate Trailer |
|710KG||Tire||Solid rubber tires|
|Gross Trailer Mass (GTM)||930KG||Brake||Handle/Hydraulic|
|Screen SIZE||2560mm(W)*1600mm(H)||Dot Pitch||6.25mm|
|Module Size||250mm(W)*250mm(H)||Brightness||≥5500cd/ m²|
|Max Power |
|700w/sqm||Average Power |
|Hydraulic lifting System|
|Hydraulic Lifting |
|Lifting Range 1000mm|
|Hydraulic Rotating System||Screen can rotate 360degrees|
|Wing-against Level||Against Level 8wind after screen lift up 1000mm|
|Input Voltage||220V||Output Voltage||48V|
|Current||15A||Average power consumption||0.5kwh/sqm|
|Multimedia Control System|
|Optional configuration||LED Screen& Battery power & mechanical transmission is optional|
|2||Pixel Pitch (mm)||6.25|
|3||Physical Density (dot/m2)||25600|
|6||Module Size (mm x mm)||250x250|
|8||Viewing Angle (Deg)||H:140 / V:140|
|10||Grey Scale||16 bits|
|11||Refresh Rate (Hz)||1920-3840|
|12||Power Consumption (W/sqm)||MAX: 700 / AVE: 275|
|13||Cabinet Size (mm x mm)||500x500|
|14||Cabinet Material||Iron / Aluminum|
|15||Input Voltage (V)||AC 110V~220V+/-10%|
|16||Refresh Frame Frequency (Hz)||60|
|18||Working Temperature (ºC)||-30°- +60°|
|19||Operation humidity (RH)||10%-95%|
Shenzhen Chuangkaiguang Co., LTD (known as CKGLED), a professional LED display factory who specializes in R&D / DESIGN / PRODUCTION /
SALES, was established in 2012 with a registered capital of more than $ 12 Million. CKGLED product ranks are indoor/outdoor rental led displays,
Ultra small pixel pitch led displays, indoor/outdoor fixed installation led displays, sports /stadium led displays, traffic led displays etc.
The company has developed a long-term development strategy plan, adhere to the "Thanksgiving, integrity, innovation, focus" business management
philosophy, to create the world's largest LED photoelectric display products integrated manufacturing service provider for the goal, we work together
for common developmen.
For iron cabinet LED display screen of indoor or outdoor, we usually use wooden case to packing
For aluminum cabinet of LED rental stage display, we usuallu use flight case to packing
One wooden case including 2 cabinets, one flight case including 6 cabinets
By air or sea, FOB shenzhen
UPS/DHL/FedEx/Express(door to door)and so on
Within 15 days counting from 30% prepayment arrived at CKGLED account.
T/T(30% deposit, the remained 70% payment made before factory shipment )
Provide details about the production procedure
Assign engineers for installation and testing
Customized solution designs
Product rendering and steel structure drawing
CKGLED's successful project examples and visits to our production and R&D base
Two-year quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material): free repair service during the quality warranty period and reasonable charge for spare parts and
maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user's notification, we ensure 24-hour after-sales technical support.
Spare parts: necessary spare parts are provided together with products to customers.
Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
Site instruction service of installation is available.
Free on-site service for hardware related issues.
Please call our technical support for more information: 0086 - 13632795492.
